    Stainless Steel Full Rugged LCD Monitor 10.4'' AR / AG Coating Treatment

    10.4 inch SVGA, XGA Rugged stainless steel full IP65 waterproof touchscreen LCD monitor displays for industrial control


    ITD rugged full IP66 LCD monitors are environmentally sealed to NEMA 4/4X & IP65 ratings for applications where dirt, dust, moisture and water are present. Our Rugged Industrial LCD products are constructed from solid steel and stainless steel for corrosion resistance applications.


    FEATURES

    - Sunlight and Daylight Readable

    - Touch Screen (PCAP, IR, Resistive optional)

    - DC Vehicle/Marine Power Supply Support

    - Waterproof All Weather Operation

    - VGA and/or HDMI Inputs

    - Brightness Control, Light Sensor (optional, 0-100%)

    - Composite Inputs Optional(Camera)


    Full IP65/IP66 Touchscreen Monitor


    Model NameITD10CMG1IP*1
    IP RatingFull IP65/IP66(IP67 optional)

    LCD Panel


    Screen Diagonal (Inch/cm)10.4”
    Display Active Screen Size (mm)211.2(H) x 158.4(V)mm
    Aspect Ratio4:3
    Physical Resolution800 x 600
    Maximum Resolution Supported1920 x 1080
    Colors16.7M
    Brightness (cd/m²)300nits
    Contrast Ratio600:1
    View Angels80/80/70/70
    Backlight/Backlight LifetimeLED Backlight with 50000 Hours’ Lifetime

    Touch Panel


    Touch OptionsResistive, PCAP
    Touch DriversWindows, Linux, Android, Mac, Raspberry Pi

    Input / Output


    Video Input1 × VGA
    N/A
    1 × HDMI(Optional)
    AudioN/A
    Touch Connector1 × USB(Optional)
    Power Connector1 × DC2.0

    Operation


    Operating Temperature Range-10~60°C (-20~70°C Optional)
    Humidity Range (RH)10-90%
    24/7/365 UseSupported

    Power


    Power IndicatorN/A
    Power InputDC 12V
    Power Consumption9W

    Order Information


    10.4”Full IP65/IP66 LCD Monitor with Resistive Touch, Aluminum HousingITD10CMT1IPA1
    10.4”Full IP65/IP66 LCD Monitor with PCAP Touch, Aluminum HousingITD10CMT5IPA1
    10.4”Full IP65/IP66 LCD Monitor with Resistive Touch, Stainless Steel HousingITD10CMT1IPS1
    10.4”Full IP65/IP66 LCD Monitor with PCAP Touch, Stainless Steel HousingITD10CMT5IPS1
    10.4”Full IP65/IP66 LCD Monitor with Tempered Glass, Aluminum HousingITD10CMG1IPA1
    10.4”Full IP65/IP66 LCD Monitor with Tempered Glass, Stainless Steel HousingITD10CMG1IPS1
