High Definition 17 Inch Open Frame Touch Screen Monitor Vertical Type

Shenzhen ITD Display Equipment Co., Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap High Definition 17 Inch Open Frame Touch Screen Monitor Vertical Type from wholesalers

    Buy cheap High Definition 17 Inch Open Frame Touch Screen Monitor Vertical Type from wholesalers
    • Buy cheap High Definition 17 Inch Open Frame Touch Screen Monitor Vertical Type from wholesalers
    • Buy cheap High Definition 17 Inch Open Frame Touch Screen Monitor Vertical Type from wholesalers

    High Definition 17 Inch Open Frame Touch Screen Monitor Vertical Type

    Ask Lasest Price
    Brand Name : ITD/OEM
    Model Number : ITD17OFN1M1
    Certification : CE, FCC, RoHS
    Price : TBA
    Payment Terms : T/T, Western Union, Paypal
    Supply Ability : 10000PCS/Month
    Delivery Time : 5-15 Business Days
    • Product Details
    • Company Profile

    High Definition 17 Inch Open Frame Touch Screen Monitor Vertical Type

    High Definition 17 Inch Open Frame Touch Screen Monitor Vertical Type


    17 inch industrial open frame LCD touchscreen monitor displays with VGA,HDMI input


    The 17” open frame touch screen monitor size is perfect for many applications that require a screen that is large enough to view and yet still able to hold a clear and crisp picture. For kiosk or medical applications that require 1280 x 1024 resolution, a tough durable chassis and the option for surface acoustic wave, IR, PCAP touchscreen monitors, our 19-inch touch screen monitor solutions are a viable alternative for your application needs.


    BENEFITES
    - Exceptional quality and highly engineered industrial monitors
    - Optional touchscreens like resistive, IR, SAW, PCAP
    - All steel construction designed for harsh and industrial environments
    - Easy-to-install cabinet and open frame rear-mount display
    - Multiple mounting options (75/100mm VESA mount and side brackets)
    - Accuracy in high-use applications
    - Long lasting product cycle for continuity thru all phases of project


    Open Frame LCD Monitor


    Model NameITD17OFN1M1
    IP RatingN/A

    LCD Panel


    Screen Diagonal (Inch/cm)17”
    Display Active Screen Size (mm)337.920(H) ×270.336(V)
    Aspect Ratio4:3
    Physical Resolution1280×1024
    Maximum Resolution Supported1920×1080
    Colors16.7M
    Brightness (cd/m²)250nits
    Contrast Ratio1000:1
    View Angels85/85/80/80
    Backlight/Backlight LifetimeLED Backlight with 50000 Hours’ Lifetime

    Touch Panel


    Touch OptionsResistive, IR, SAW, PCAP
    Touch DriversWindows, Linux, Android, Mac, Raspberry Pi

    Input / Output


    Video Input1 × VGA
    1 × DVI-I
    1 × HDMI
    Audio1 × PC-Audio
    Touch Connector1 × USB
    Power Connector1 × DC2.0

    Operation


    Operating Temperature Range-10~60°C (-20~70°C Optional)
    Humidity Range (RH)10-90%
    24/7/365 UseSupported

    Power


    Power IndicatorGreen LED
    Power InputDC 12V
    Power Consumption15W

    Order Information


    17”Open Frame LCD Monitor with Resistive TouchITD17OFT1M1
