    17" High Reliability Rugged All In One PC Sunlight Readable DC12V 34 Watt Power

    Ask Lasest Price
    Brand Name : ITD/OEM
    Model Number : ITD17PPCT1IPHBS2
    Certification : CE, FCC, RoHS
    Price : TBA
    Payment Terms : T/T, Western Union, Paypal
    Supply Ability : 5000PCS/Month
    Delivery Time : 15-20 Business Days
    • Product Details
    • Company Profile

    17" High Reliability Rugged All In One PC Sunlight Readable DC12V 34 Watt Power

    17"sunlight readable full IP66 waterproof touch Panel PC computer optical bonding AR coating

    ITD’s 17.0" Robust full IP65 stainless steel high bright sunlight readable panel PC, Harsh-Duty LCD Display System is waterproof to IP66 standards and engineered to withstand the harshest environments and most demanding real world applications. The optically bonded high bright display with touch screen is for true sunlight readability, exceptional clarity, and wide viewing angles.

    BENEFITES
    - 17" Industrial Grade TFT Panel Display, 1500 nits cd/m2
    - True High Brightness Low-Power, high reliability Solid State LED Backlighting:
    - Resolution: 1280 x 1024 native
    - Optical Bonded Between TFT Panel and Touch Panel Optional
    - Advanced Deep Dimming to Black Optional
    - Engineered for All-Weathers even in direct sunlight
    - Mounting Configurations: VESA,
    - Default Waterproof Conectors: USB, Power Input, RJ45
    - Machined NEMA 4 (IP65) Rated, Black Powder Coated, Very Rugged Stainless Steel or Aluminum Gasket Sealed Enclosure

    Applications for Rugged Rugged Panel PCs
    - Food processing plant automation control
    - Kitchen application
    - Chemical plant or laboratory
    - Liquor Factory
    - Clinical area / pharmaceutical / medical
    -Operating and monitoring in Oil, Gas & Energy industry
    - Industrial automation control in slaughtering house
    - Railway/Transportation

    High Brightness Full IP65/IP66 Panel PC

    Model NameITD17PPCG1IPHB**
    IP RatingIP65/IP66(IP67 optional)

    PC Systems Options

    ARM Android Based RK3288(RK3368 optional)X86 Windows BasedX86 Windows Based
    CPU: Quad-Core Cortex-A17 1.8GHzCPU: Intel® Celeron J1900CPU: Intel Core i3/i5/i7
    Chipset: N/AChipset: Intel® NM10 ExpressChipset: Intel® HD Graphics, Support 1080p
    Memory: 1G/2GMemory: 2GB(Max. 8GB)Memory: 2GB(Max. 8GB)
    HDD/SSD: 8GHDD/SSD:500G/64GHDD/SSD:500G/64G
    1×HDMI1×VGA, 1×HDMI1×VGA, 1×HDMI
    1×USB 2.02×USB 2.0, 2×USB3.02×USB 2.0, 2×USB3.0
    1×mini-SD slot1×COM(RS232/422/485)1×COM(RS232/422/485)
    1×LAN1×LAN1×LAN
    1×Audio Out1×Audio Out, 1×MIC In1×Audio Out, 1×MIC In
    Expansion: SSDExpansion: USB, COM, Mini-PCIeExpansion: USB, COM, Mini-PCIe
    Default IP65 Connectors: 1×USB 2.0, 1×LAN, 1×DC 2.0

    LCD Panel

    Screen Diagonal (Inch/cm)17”
    Display Active Screen Size (mm)337.920(H) ×270.336(V)
    Aspect Ratio4:3
    Physical Resolution1280×1024
    Maximum Resolution Supported1920×1080
    Colors16.7M
    Brightness (cd/m²)1000 cd/m²
    Contrast Ratio1000:1
    View Angels85/85/80/80
    Backlight/Backlight LifetimeLED Backlight with 50000 Hours’ Lifetime

    Touch Panel

    Touch OptionsResistive, PCAP
    Touch DriversWindows, Linux, Android, Mac, Raspberry Pi

    Operation

    Operating Temperature Range-10~60°C (-20~70°C Optional)
    Humidity Range (RH)10-90%
    24/7/365 UseSupported

    Power

    Power IndicatorGreen LED
    Power InputDC12V
    Power Consumption34W

    Order Information

    17”1000nits Full IP65/IP66 Stainless Steel Panel PC with Resistive Touch, J1900ITD17PPCT1IPHBSJ1
    17”1000nits Full IP65/IP66 Stainless Steel Panel PC with PCAP Touch, J1900ITD17PPCT5IPHBSJ1
    17”1000nits Full IP65/IP66 Stainless Steel Panel PC with Tempered Glass, J1900ITD17PPCG1IPHBSJ1
    17”1000nits Full IP65/IP66 Stainless Steel Panel PC with Resistive Touch, i3ITD17PPCT1IPHBSI3
    17”1000nits Full IP65/IP66 Stainless Steel Panel PC with PCAP Touch, i3ITD17PPCT5IPHBSI3
    17”1000nits Full IP65/IP66 Stainless Steel Panel PC with Tempered Glass, i3ITD17PPCG1IPHBSI3
    17”1000nits Full IP65/IP66 Aluminum Alloy Panel PC with Resistive Touch, J1900ITD17PPCT1IPHBAJ1
    17”1000nits Full IP65/IP66 Aluminum Alloy Panel PC with PCAP Touch, J1900ITD17PPCT5IPHBAJ1
    17”1000nits Full IP65/IP66 Aluminum Alloy Panel PC with Tempered Glass, J1900ITD17PPCG1IPHBAJ1
    17”1000nits Full IP65/IP66 Aluminum Alloy Panel PC with Resistive Touch, i3ITD17PPCT1IPHBAI3
    17”1000nits Full IP65/IP66 Aluminum Alloy Panel PC with PCAP Touch, i3ITD17PPCT5IPHBAI3
