    Flat Surace Panel Mount Touch Screen PC 21.5 Inch 1920X1080 Resolution

    Ask Lasest Price
    Brand Name : ITD/OEM
    Model Number : ITD21PPCG1X**
    Certification : CE, FCC, RoHS
    Price : TBA
    Payment Terms : T/T, Western Union, Paypal
    Supply Ability : 10000PCS/Month
    Delivery Time : 5-15 Business Days
    • Product Details
    • Company Profile

    Flat Surace Panel Mount Touch Screen PC 21.5 Inch 1920X1080 Resolution

    IP65 front true flat surace 21.5" panel mount touch PC

    FEATURES

    - Supports Intel Celeron CPU up to 2.0 GHz

    - Low power consumption and economical solution

    - Compact size and high performance

    - High speed Giga LAN

    - On-board IDE interface

    - High precision touchscreen

    - Industry level of durability against dust and powerful jetting IP65 / NEMA 4


    Specifications:


    Flat Bezel Industrial Panel PC


    Model NameITD21PPCG1X**
    IP RatingIP65 Front Panel

    PC Systems Options


    ARM Android Based RK3288(RK3368 optional)X86 Windows BasedX86 Windows Based
    CPU: Quad-Core Cortex-A17 1.8GHzCPU: Intel® Celeron J1900CPU: Intel Core i3/i5/i7
    Chipset: N/AChipset: Intel® HD Graphics, Support 1080pChipset: Intel® HD Graphics, Support 1080p
    Memory: 1G/2GMemory: 2GB(Max. 8GB)Memory: 2GB(Max. 8GB)
    HDD/SSD: 8GHDD/SSD:500G/64GHDD/SSD:500G/64G
    1×HDMI1×VGA, 1×HDMI1×VGA, 1×HDMI
    1×USB 2.02×USB 2.0, 2×USB3.02×USB 2.0, 2×USB3.0
    1×mini-SD slot1×COM(RS232/422/485)1×COM(RS232/422/485)
    1×LAN1×LAN1×LAN
    1×Audio Out1×Audio Out, 1×MIC In1×Audio Out, 1×MIC In
    Expansion: SSDExpansion: USB, COM, Mini-PCIeExpansion: USB, COM, Mini-PCIe

    LCD Panel


    Screen Diagonal (Inch)21.5”
    Display Active Screen Size (cm)476.64(H)×268.11(V)
    Aspect Ratio16:9
    Physical Resolution1920×1080
    Maximum Resolution Supported1920×1080
    Colors16.7M
    Brightness (cd/m²)250
    Contrast Ratio1000:1
    View Angels85/85/80/80
    Backlight/Backlight LifetimeLED Backlight with 50000Hours'Lifetime

    Touch Panel


    Touch OptionsResistive, IR, PCAP, SAW
    Touch DriversWindows, Linux, Android, Mac, Raspberry Pi

    Operation


    Operating Temperature Range-10~60°C (-20~70°C Optional)
    Humidity Range (RH)10-90%
    24/7/365 UseSupported

    Power


    Power IndicatorGreen LED
    Power InputDC 12V
    Power Consumption36.25W

    Order Information


    21.5”Panel Mount Panel PC with Resistive Touch, J1900ITD21PPCT1XJ1
    21.5”Panel Mount Panel PC with PCAP Touch, J1900ITD21PPCT5XJ1
    21.5”Panel Mount Panel PC with Tempered Glass, J1900ITD21PPCG1XJ1
    21.5”Panel Mount Panel PC with Resistive Touch, i5ITD21PPCT1XI5
    21.5”Panel Mount Panel PC with PCAP Touch, i5ITD21PPCT5XI5
    21.5”Panel Mount Panel PC with Tempered Glass, i5ITD21PPCG1XI5

    The ITD all-in-one Embedded Panel PCs with x86 open platform and preinstalled Windows Embedded operating systems enable fast and economical deployment of improved HMI systems for operator control and monitoring applications. The Celeron J1900 processor was produced by Intel as a high-powered chip that would work in a wide range of thermal conditions, making it a highly desirable solution for industrial control applications.



    Product Display:



    APPLICATION
