    Black Shell Mini Embedded Industrial PC With Intel I3/I5/I7 Processor

    Ask Lasest Price
    Brand Name : ITD/OEM
    Model Number : ITD-MNPC-X31-I3/I5/I7
    Certification : CE, FCC, RoHS
    Price : TBA
    Payment Terms : T/T, Western Union, Paypal
    Supply Ability : 10000PCS/Month
    Delivery Time : 5-15 Business Days
    • Product Details
    • Company Profile

    Black Shell Mini Embedded Industrial PC With Intel I3/I5/I7 Processor

    MINI PC embedded industrial PC with Intel i3/i5/i7 processor


    Specifications:


    Industrial Embedded Box PC


    Model NameITD-MNPC-X31-I3/I5/I7
    IP RatingN/A

    PC Systems


    CPU

    Intel® Core® i3/i5/i7 Processor (i3-5005U/i5-5200U/i7-5500U;

    i3-6100U/i5-6200U/i7-6500U;

    i3-7100U/i5-7200U/i7-7500U)

    ChipsetIntel® HD Graphics
    GraphicsIntel® HD Graphics
    AudioMIC-IN, LINE-OUT
    Memory2GB, up to Max. 8GB
    Storage320GB SATA up Max. 1TB; 32GB SSD up to Max. 512GB (MSATA Supported)
    Driver SupportWindows CE/XP/7/8/10, Linux,

    I/O


    Serial Ports2 x COM
    USB Ports2 x USB2.0, 4 X USB3.0
    HDMI Port1 x HDMI
    VGA Port1 x VGA
    Mini PCIeN/A
    AudioMIC-IN, LINE-OUT
    Communication (3G/4G, WIFI)Optional
    LAN1 x 10/100/1000Mbps Ethernet
    Power Port1 x DC 12V Input (1 x ON/OFF Power Switch)

    Power


    Power IndicatorGreen LED
    Power InputDC 12V
    Power ConsumptionTBA

    Operation/Mechanical


    Operating Temperature-10~60℃
    Humidity Range20%~90% (Non Condensing)
    Housing MaterialAluminum Die-Casting
    Housing Dimension (L × W × H)180mm x 128mm x 55mm

    ITD Industrial Embedded Box PC is ultra-compact industrial computer for repetitive machines and infrastructures. It utilizes an Intel® Celeron® Processor N2830, on-board non-volatile DDR3L-1333 memory and a standard SD card slot. This delivers a great combination of performance, features and functionality at an affordable price, which offer real-time performance, compact footprint and lightweight aluminum die-cast housing and are easy to service, maintenance-free, space-saving and fan-less.


    BENEFITES

    • IoT gateway ready for future requirements
    • Energy-efficient and fan-less IPC Systems
    • Intel Celeron® N2930, 2M Cache, 2.16 GHz
    • Maintenance-free with no rotating disk (HDD)
    • Robust aluminum die-casting housing
    • Power-optimized PC with 32- or 64-bit OS
    • High system availability and data security
    • High data transfer rates and redundancy

    APPLICATION
