    10.1 Inch Desktop All In One Industrial Panel Pc Touch Screen Android 6.0/7.1 For Self Service Photo Printing

    Ask Lasest Price
    Brand Name : ITD/OEM
    Model Number : ITD0101PPCT5XE2
    Certification : CE/ROHS/FCC
    Payment Terms : T/T, Western Union,Paypal
    Supply Ability : 10000 unit per month
    Delivery Time : 7-12 work days
    Price : TBA
    • Product Details
    • Company Profile

    10.1 Inch Desktop All In One Industrial Panel Pc Touch Screen Android 6.0/7.1 For Self Service Photo Printing

    10.1 inch desktop all in one multi touch screen panel PC Android 6.0/7.1 for self-service photo printing


    ITD New Series multi-touch screen HMI comfort panel PC is fully-integrated‚ multi capacitive touch screen combines Android RK3328 media player, and Projected Capacitive Touch (PCT or PCAP)Technology in TFT LCD flat panels, with sleek and flat front surface commercial design. This PCT technology is a capacitance system that delivers sensitive and accurate 10 multi-touch interactive experiences. The ITD multi-touch HMI comfort panel PC specifically suited for various interactive digital signage applications.


    PARAMETERS

    PanelCell Type/Glass SurfaceTFT
    Size/ Aspect Ratio10.1”/16:9
    Active Area/ Pixel Pitch222.52(W) x 125.11(H)mm /0.1629 × 0.1629mm
    Native Resolution/ Colors1366x 768/ 16.7M
    Brightness/ Contrast300cd/㎡/800:1
    Response Time25ms
    Viewing Angle(Typical)85/85/85/85
    Light SourceLED Backlight with 50000Hours’Lifetime

    SPECIFICATION

    System

    CPU: ARM Quad Core RK3288,Main CPU frequency:1.8GHz

    GPU: Mali-T764 GPU

    SDRAM: 2G; 4G Optional

    Flash: 8G: 16G/32G/64G/128G Optional

    OS: Android 5.1/6.0; Bluetooth: Optional

    Video Decoder: 4K VP8 and 4K 10bits H265/H264

    1080P other video decoders (VC-1, MPEG-1/2/4, VP8)

    Media Format: Supports RMVB,FLV,MPEG1/2/4,AVI,WMV,MOV,MP4,TS,etc

    Music Format: Support MP3/AAC/WAV/WMA/Dolby True HD/DTS-HD/LPCM

    /H264/VP8/MVC

    Photo Format: Supports JPG/BMP/GIF/TIFF/PNG

    Input / Output

    1 × HDMI; 2 × USB Max. 4× USB; 1 × USB OTG; 4 × COM;

    1 × TF Card Support 8~128GB; 1 × DC 12V 2.0; 3G/4G Optional

    1 × RJ45 LAN Ethernet 10/100/1000M (Realtek RTL8211E);

    Operating Temperature-10~60℃ (-20~70℃ Optional)
    Storage Temperature-20~70℃
    Relative Humidity10%~90% (Non Condensing)
    Order Information10.1”Zero-Bezel Android Panel PC with PCAP Touch/ITD101PPCT5KXE31
    10.1”Zero-Bezel Android Panel PC with Resistive Touch/ITD101PPCT1KXE31
    10.1”Zero-Bezel Android Panel PC with Tempered Glass/ITD101PPCG1XE31

    FEATURES

    • Centralized server controls content distribution;

    • Combined hardware and software solution for fast, reliable delivery of digital signage content and continuous operation;

    • Easy WIFI network system installation without the need for extra IT, firewall or security configurations;

    • Simple content scheduling and updating for each display;

    • Restart and update digital signage players remotely;

    • Create and update separate schedules for each display, al owing for targeted ads at each terminal or different locations;

    • Deliver rich media including: Multiple video and audio formats, RSS feeds and image slide shows;

    • Transfer schedules and contents to one or more displays;

    • Control, monitor and design screen layouts remotely by the admin software;

    • Support Multi-zone terminal display and flexible screen layout;

    • Local review of multi-zone display layout once the content is stored in the server PC;

    • Manage daily power on/off time for any display or group of displays;

    • Content plays automatically upon set up of schedule;

    • Display live news, weather, traffic reports, emergency announcements and many other notices;

    • Remotely report system utilization and memory usage;

    • System automatically notifies administrator of any malfunction;

    • Daily, monthly display content recording;

    • Possible to integrate with the any existing management system.


    Product Display:
