    TPM 2.0 Fanless Touch Panel PC Intel I3 I5 I7 Windows 10 11 350nits PCAP IR

    Ask Lasest Price
    Brand Name : ITD/OEM
    Model Number : ITDxxPPCT5LIx
    Certification : CE, FCC, RoHS
    Price : TBA
    Payment Terms : T/T, Western Union, Paypal
    Supply Ability : 10000PCS/Month
    Delivery Time : 15-20 Business Days
    • Product Details
    • Company Profile

    TPM 2.0 Fanless Touch Panel PC Intel I3 I5 I7 Windows 10 11 350nits PCAP IR

    fanless industrial touch panel PC Intel i3 i5 i7 Windows 10 11 TPM 2.0


    ModelITD10PPCN1LI*ITD12PPCN1LI*ITD15PPCN1LI*ITD156PPCN1LI*ITD17PPCN1LI*
    Size10.4” (4:3)12.1” (4:3)15” (4:3)15.6” (16:9)17” (4:3)
    Active Area211.2(W) x 158.4(H)246.0(H) x 184.5(V)304.128(H)x 228.096(V)246.0(H) x 184.5(V)337.920(H) x 270.336(V)
    Contrast500:1500:1700:1700:11000:1
    Resolution800 x 600 or 1024 x 768800 x 600 or 1024 x 7681024 x 7681920 x 10801280 x 1024
    Brightness350nits350nits250nits300nits250nits
    Viewing Angles70/70/60/7070/70/60/7080/80/60/7089/89/89/8985/85/80/80
    BacklightLEDLEDLEDLEDLED
    ModelITD173PPCN1LI*ITD18PPCN1LI*ITD19PPCN1LI*ITD21PPCN1LI*ITD24PPCN1LI*
    Size17.3” (16:9)18.5” (16:9)19” (4:3)21.5” (16:9)24” (16:9)
    Active Area381.888(H) x 214.812(V)409.8(H) x 230.4(V)376.32(H) x 301.06(V)476.64(H) x 248.25(V)531.36(H) x 298.89(V)
    Contrast400:11000:11000:11000:11000:1
    Resolution1920 x 10801366 x 7681280 x 10241920 x 10801920 x 1080
    Brightness300nits250nits250nits250nits300nits
    Viewing Angles70/70/60/6085/85/80/8085/85/80/8085/85/80/8089/89/89/89
    BacklightLEDLEDLEDLEDLED
    ModelITD27PPCN1LI*ITD32PPCN1LI*ITD42PPCN1LI*ITD55PPCN1LI*ITD65PPCN1LI*
    Size27” (16:9)32” (16:9)42”/43” (16:9)55” (16:9)65” (16:9)
    Active Area597.6(H)x 336.15(V)698.4(H) x 392.85(V)930.24(H) x 523.26(V)1213.6(H) x 684.4(V)1428.48(W) × 803.52(H)
    Contrast1000:11000:11200:13000:14000:1
    Resolution1920 x 10801920 x 10801920 x 10801920 x 10801920 x 1080
    Brightness300nits350nits400nits400nits400nits
    Viewing Angles89/89/89/8989/89/89/8989/89/89/8989/89/89/8989/89/89/89
    BacklightLEDLEDLEDLEDLED
    SPECIFICATION
    SystemCPUIntel® Core i3/i5/i7 Processor
    BIOSUEFI
    ChipsetIntel® HD Graphics (By CPU); Shared Memory
    Memory2 x SO-DIMM, DDR3 1333MHz Memory, 4GB, Max.16GB
    Graphic ChipsetCPU integrated graphics HD and support 1080p
    Storage64GB SSD or 500GB HDD
    LAN1 x 10/100/1000Mbps Ethernet
    Input/OutputSerial Ports1 x COM
    USB Ports4 xUSB
    VGA Port1 x VGA
    HDMI Port1x HDMI Port
    Audio CardLine-In/Line-Out/Speaker MIC IN
    PowerInput VoltageExternal Power Supply DC 12V for 10.1”~24”; Internal Power Supply AC100~240V for 27”~65”
    Operation/Power Saving30-220W
    Environment ConsiderationsOperating Temperature-10~60℃ (-20~70℃ Optional)
    Storage Temperature-20~70℃
    Relative Humidity10%~90% (Non Condensing)
    OS SupportWindows 7/ Windows XP/ Windows 8/ Windows 10/Linux
    Mounting MethodVESA, Side mounting brackets(Optional)
    Order InformationChassis Panel PC i3 with Resistive Touch/ITD**PPCT1LI3
    Chassis Panel PC i3 with IR Touch/ITD**PPCT2LI3
    Chassis Panel PC i3 with PCAP Touch/ITD**PPCT5LI3
    Chassis Panel PC i5 with Resistive Touch/ITD**PPCT1LI5
    Chassis Panel PC i5 with IR Touch/ITD**PPCT2LI5
    Chassis Panel PC i5 with PCAP Touch/ITD**PPCT5LI5
    Chassis Panel PC i7 with Resistive Touch/ITD**PPCT1LI7
    Chassis Panel PC i7 with IR Touch/ITD**PPCT2LI7
    Chassis Panel PC i7 with PCAP Touch/ITD**PPCT5LI7

    Note: The exterior design for each size is subject to its drawings.
