    24 Inch Flat LCD Monitor Touch Screen 1500nits For Smart Parking

    Ask Lasest Price
    Brand Name : ITD/OEM
    Model Number : ITD24OFT5Y1
    Certification : CE, FCC, RoHS
    Price : TBA
    Payment Terms : T/T, Western Union, Paypal
    Supply Ability : 10000PCS/Month
    Delivery Time : 3-15 Business Days
    • Product Details
    • Company Profile

    24 Inch Flat LCD Monitor Touch Screen 1500nits For Smart Parking

    24 inch flat lcd monitor touch screen 1500nits for smart parking


    APPLICATIONS of monitor touch screen 1500nits:

    • Warehouse&Logistics
    • Healthcare
    • Public Safety
    • Government
    • Smark Parking
    • Gas Pumps
    • Outdoor Self-Service Terminals

    Description of 24 flat lcd monitor

    ModelITD24OFT5Y1
    IPIP65(for front panel only)
    Outline DimensionsWidth: 586.2mm Height: 358.2mm Depth: 54.31mm
    Weight(N.W/G.W)6.57kg
    Packing DimensionTBA
    LCD Type23.6"Active matrix TFT-LCD
    Video InputVGA/HDMI
    Recommend Resolution1920×1080@60Hz,75Hz
    OSD controlsAllow On-Screen Adjustments of Brightness, Contrast Ratio, Auto-adjust, Phase, Clock, H/V Location, Languages, Function, Reset
    Power SupplyType: External Brick
    Input (line) Voltage: 100-240 VAC, 50-60 Hz
    Output Voltage/Current: 12V at 5A
    Power Consumption24W
    Mount Interface

    1)VESA 75mm and 100mm

    2)Rear Mounting Brackets

    Regular Warranty2 Years
    Agency ApprovalFCC,CE,RoHS Certified

    2.2 LCD Specification

    Active Area(mm)521.28(H)×293.22(V)
    Resolution1920×1080
    Pixel Pitch(mm)0.2715×0.2715
    Nominal Input Voltage VDD+5V(Typ)
    Viewing angle (L/R/T/B)89°/89°/89°/89°
    Contrast3000:1
    Luminance(cd/m2)300 1000nits, 1500nits optional
    Response Time(Rising/Falling)10ms
    Support Color16.7M
    Screen Scanning60Hz
    Backlight MTBF(hr)50000h

    2.3 Touch Screen Specification

    TypeProjected Capacitive Touch Screen
    Resolution4096×4096
    Light Transmission85%±5%
    Touch Life Cycle50 millions times
    Touch Response time5ms
    Touch System InterfaceUSB B type
    Operating System Support

    Plug and Play for Windows 7/8/10,Linux Kernel 3.18.12 or above

    Drivers for Windows CE/XP, Android, Mac

    2.4 External AC Power Adapter

    Output12V DC/4A (24V DC, 9-36V DC optional)
    Input100-240 VAC, 50-60 Hz
    MTBF50000 hr at 25°C

    2.5 Environment

    Operating Temp.-10~60°C (-20~70°C optional)
    Storage Temp.-20~70°C
    Operating RH:10%~90% (Non Condensing)
    Storage RH:10%~90%
