    10.1" Industrial Touch Screen Panel PC Intel J6412 IP65 Front Panel Mount / VESA Mounting

    Ask Lasest Price
    Brand Name : ITD/OEM
    Model Number : ITD101PPCT5B-J6412
    Certification : CE, FCC, RoHS
    Price : TBA
    Payment Terms : T/T, Western Union, Paypal
    Supply Ability : 5000PCS/Month
    Delivery Time : 5-10 Business Days
    • Product Details
    • Company Profile

    10.1" Industrial Touch Screen Panel PC Intel J6412 IP65 Front Panel Mount / VESA Mounting

    industrial panel mounted touch screen pc 10.1" Intel J6412 IP65 front


    Features of IP65 touch screen pc

    • Onboard Intel® Celeron J4125/J6412 or 8th/10th intel Core i5/i7
    • J4125/J6412: DDR4 SODIMM x1; Core 5/i7: DDR4 SODIMM x2
    • L CD+HDMI Output, Support Dual view/Simultaneous display
    • IP65 Front Bezel
    • Fanless Operation
    • Wide DC Support 9 ~ 36V

    Applications of industrial touch screen PC

    • Automation
    • Transportation&Logistics
    • Robots
    • IoT
    • Marine
    • Self-Service Terminals

    Processorlntel Celeron J4125/J6412 CPU
    lntel Core 8/10/11代-U i5/i7 CPU
    System MemoryJ4125/J6412: DDR4 SODIMM x1
    Core i5/i7: DDR4 SODIMM x2
    Ethernet2x 2.5 GbE R
    J45 Intel® i225V (4 x 2.5GbE RJ45 Intel i225V)
    I/O Port

    4 x USB2.0 , 2 x USB3.0 (J4125/J6412)
    1 1 2 x USB2.0 , 4 x USB3.0 (8th/10th/11th intel Core i5/i7)
    2 x DB-9 COM1&COM2,RS-232/422/485

    1 x Audio Line-out

    2 x 8Ω 1W Audio AM P out (Optional)

    1 x AT/ATX switch

    1 x HDMI

    1 x Expansion IO:4x3-wire COM, 1 x10bit GPIO,
    1x Remote switch

    Storage Disk Driver1 x M.2 2242/2260/2280 SATA
    1 x SATA(2.5'' SATA )
    1 x M.2 2280 NVME
    Expansion SlotM.2 3042/3052 with SIM Card for 3G/4G/5G
    M.2 2230 WiFi/Bluetooth
    Watchdog timer1~655 35S
    OS supportWindows® 10/11, WES 10, LINUX
    ConstructionAluminum
    MountingVESA 75/ 100 Panel mount

    Operating TMP-20°C ~ 60 °C
    Storage TMP- 30°C ~ 70°C
    Storage Humidity10~90% @30°C, non-condensing
    DC InputDC 9 ~ 36V 4-pin M12 connector
    Display Type10.1" TFT-LCD
    Max.Resolution1280x800( Optional 1024 x 600 )
    Max.Colors16.2M
    Luminance400 cd/m²
    Viewing Angle(CR>=10)-8 5 ~ 8 5 ° ( H) , - 8 5 ~ 8 5 ° ( V )
    Back Light MTBF (hours30000H
