    Embedded Touch Panel PC 7'' Windows 10 CE Linux Android 1024 X 600 Resolution

    Ask Lasest Price
    Brand Name : ITD/OEM
    Model Number : ITD07PPCT5XJ1
    Certification : CE/ROHS/FCC
    Payment Terms : T/T, Western Union,Paypal
    Supply Ability : 10000 unit per month
    Delivery Time : 7-12 work days
    Price : TBA
    • Product Details
    • Company Profile

    Embedded Touch Panel PC 7'' Windows 10 CE Linux Android 1024 X 600 Resolution

    7 inch industrial embedded pc panel touch screen windows 10 CE Linux Android


    The ITD industrial multi-touch screen panel mounted panel PC is fully-integrated‚ multi capacitive touch screen that combines high-performance Intel® Celeron™ Quad Core Processor J1900 2.0 GHz with Projected Capacitive Touch (PCT or PCAP) Technology in a sleek industrial-grade IP65/ NEMA 4/4x Ingress rating TFT-LCD flat panel with flat front surface design. The ITD Windows-based control panel is Commercial Off-the-Shelf (COTS) unit and allows easy access to ten-touch capabilities built into Windows 7/8 and other popular programming languages. The ITD multi-touch panel mounted panel PC is designed for industrial, process manufacturing, discrete manufacturing, industrial automation, building automation, process control, access control, room reservation, room scheduling, medical healthcare, kiosks, machinery manufacturing, and custom machine to machine interface applications.


    FEATURES
    Easy-to-clean, true flat front surfacewithout bezel
    Flexible, reliable, and ruggedizedtouch screen computers for open platform HMI/SCADA
    Ten independent touch points (withWindows 7/8/10, Android, Linux operating systems)
    Eliminates dust and debris build-up atthe edge and corners of the display
    Provides improved power efficiency andreduced consumption
    Responds to a light touch to activateresponse
    Ruggedized levels of NEMA 12, NEMA 4,IP52, IP54, IP65 ratings for front panel
    Aluminum front bezel and steel chassisconstruction designed for harsh and industrial environments
    CE, FCC, RoHS Compliance

    SPECIFICATION

    PanelCell Type/Glass SurfaceTFT
    Size7”
    Aspect Ratio16:9
    Active Area154.214(H) x 85.92(V)mm
    Pixel Pitch0.1506 × 0.1432mm
    Native Resolution1024 x 600
    Colors262K/16.7M
    Brightness500cd/㎡
    Contrast800:1
    Response Time10/15ms
    Viewing Angle(Typical)75/75/70/75
    Light SourceLED Backlight with 50000Hours’Lifetime
    SystemCPUIntel® Celeron J1900 2.0GHz Processor
    BIOSAMI
    ChipsetSOC
    Memory2xSO-DIMM, DDR3L-1333MHz Memory, 4GB, Max.8GB
    Graphic ChipsetIntel® HD Graphics
    Storage1 x SATA, 1 x mSATA, Default to 64GB SSD
    LAN1 x 10/100/1000Mbps Ethernet
    Input / OutputSerial Ports1 x COM
    USB Ports4 X USB 2.0
    VGA Port1 x VGA (Max. 1920x 1080@60Hz)
    HDMI Port1x HDMI (Max. 2560 x 1600@60Hz)
    Audio Card

    with Realtek ALC662

    Line-Out /MIC IN

    PowerInput VoltageDC 12V
    Operation/Power Saving15W
    Environment ConsiderationsOperating Temperature-10~60℃ (-20~70℃ Optional)
    Storage Temperature-20~70℃
    Relative Humidity10%~90%
    Order Information7” Flat Bezel Panel PC with PCAP Touch J1900/ITD07PPCT5XJ1
    7” Flat Bezel Panel PC with Tempered GlassJ1900/ITD07PPCG1XJ1
