Android 7.0 20W 10.4" 1000nits Touch Panel Fanless PC SCADA

Shenzhen ITD Display Equipment Co., Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap Android 7.0 20W 10.4" 1000nits Touch Panel Fanless PC SCADA from wholesalers

    Buy cheap Android 7.0 20W 10.4" 1000nits Touch Panel Fanless PC SCADA from wholesalers
    • Buy cheap Android 7.0 20W 10.4" 1000nits Touch Panel Fanless PC SCADA from wholesalers
    • Buy cheap Android 7.0 20W 10.4" 1000nits Touch Panel Fanless PC SCADA from wholesalers

    Android 7.0 20W 10.4" 1000nits Touch Panel Fanless PC SCADA

    Ask Lasest Price
    Brand Name : ITD/OEM
    Model Number : ITD10PPCT1HBLJ2/ITD10PPCT5HBLJ2/ITD10PPCG1HBLJ2
    Certification : CE, FCC, RoHS
    Price : TBA
    Payment Terms : T/T, PayPal(173515844@qq.com)
    Supply Ability : 10000PCS/Month
    Delivery Time : 7-10 Business Days
    • Product Details
    • Company Profile

    Android 7.0 20W 10.4" 1000nits Touch Panel Fanless PC SCADA

    10.4”Industrial High Brightness touch Panel PC


    ITD 10.4” ITD10PPCT1HBLJ2 Low cost PPC series with rugged metal chassis, provides OEMs with vast selection of technologies and solutions simplifying PLC, HMI and SCADA applications. These PCs feature Intel® Celeron™ Quad Core Processor J1900 2.0 GHz, in industrial-grade LCD flat panels with resistive touch technology and NEMA 4 IP65 front bezel optional designed for HMI display and visualization solutions.


    Specifications:


    SystemCPUIntel® Celeron J1900 2.0GHz Processor
    BIOSAward BIOS 4/8Mbit SPI Flash ROM
    ChipsetIntel® NM70 Express Chipset
    Memory1*SO-DIMM, DDR3 1333MHz Memory, 2GB, Max.8GB
    Graphic ChipsetCPU integrated graphics HD and support 1080p
    Storage32GB SSD or 320GB HDD
    LAN1 x 10/100/1000Mbps Ethernet
    Input/OutputSerial Ports1 x COM
    USB Ports4 X USB
    VGA Port1 x VGA
    HDMI Port1x HDMI Port
    Audio Card

    with Realtek ALC662

    Line-In/Line-Out/Speaker out with 3W AMP Circuit/MIC IN

    PanelCell Type/Glass SurfaceTFT
    Aspect Ratio/Size10.4” 4:3
    Active Area/Pixel Pitch211.2(W) x 158.4(H)/0.264
    Native Resolution/Colors800 x 600 /16.7M
    Brightness/Contrast1000nits/500:1
    Viewing Angle(Typical)70/70/60/60
    Light SourceLED
    Convenient FeaturesBacklight adjustment, Plug & Play, OSD Multi-Languages
    PowerInput VoltageAC 100V~240V, 50/60Hz
    Operation/Power Saving20W(Max)
    Output Voltage+12V 4A
    Environment ConsiderationsOperating Temperature-10~60 deg.C
    Storage Temperature-30~80 deg.C
    Relative Humidity5%-95%
    OS SupportWindows 7/ Windows XP Embedded/ Windows XP Embedded/ Linux/ Win CE
    Touch Panel/InterfaceOptional
    Order Information10.4” Industrial high brightness panel PC with resistive touch/ITD10PPCT1HBLJ2
    10.4” Industrial high brightness panel PC with IR touch/ITD10PPCT2HBLJ2
    10.4” Industrial high brightness panel PC with PCAP touch/ITD10PPCT5HBLJ2
    10.4” Industrial high brightness panel PC with tempered glass/ITD10PPCG1HBLJ2
    10.4” Industrial high brightness panel PC without touch/ITD10PPCN1HBLJ2

    Product Image



    Quality Android 7.0 20W 10.4" 1000nits Touch Panel Fanless PC SCADA for sale
