    23.6" round touchscreen AIO display industrial touch panel PC for Various Industrial Applications

    Ask Lasest Price
    Brand Name : ITD/OEM
    Model Number : ITD23PPCT5Rxx
    Certification : CE, FCC, RoHS
    Price : TBA
    Payment Terms : T/T, Western Union, Paypal
    Supply Ability : 10000PCS/Month
    Delivery Time : 7-10 Business Days
    • Product Details
    • Company Profile

    23.6" round touchscreen AIO display industrial touch panel PC for Various Industrial Applications

    23.6" round touchscreen AIO display industrial touch panel PC for Various Industrial Applications


    ITD's 23.6" round touchscreen AIO display is a cutting-edge solution designed for unique and innovative applications. With its sleek circular design, high-resolution display, and responsive PCAP touch technology, this all-in-one system delivers an engaging and modern user experience. Engineered for durability and seamless integration, it is ideal for gaming, retail, kiosks, and industrial automation. Whether enhancing interactive signage or creating futuristic control interfaces, ITD’s 23.6" round touchscreen display offers versatility, reliability, and a striking visual impact.


    PanelCell Type/Glass SurfaceTFT-LCD
    Size/ Aspect Ratio23.6”
    Active Area/ Pixel Pitch599.424(W)×599.424(H) mm/0.4683 × 0.4683mm
    Native Resolution/ Colors1280×1280/16.7M
    Brightness/ Contrast700cd/㎡(1500 cd/㎡optional)/1000:1
    Response Time/ Viewing Angle(Typical)14ms/89/89/89/89
    Light SourceLED Backlight with 50000Hours’Lifetime

    SYSTEM

    ItemARM SolutionX86 Solution 1X86 Solution 2
    CPUARM Quad Core Cortex-A17 RK3288, 1.8GHz (RK3399/RK3568//RK3576/RK3588 optional)Intel® Celeron J1900/J4125/J6412 2.0GHz

    Intel® Core i3/i5/i7

    (4th~13th Generation or newer optional)

    ChipsetRockchipIntel Bay Trail SoCIntel SoC Chipset
    Memory

    2GB; 4GB/8GB Optional


    Dual Channel, DDR3 1333/1600MHz Memory,

    Max.8GB; DDR4 SODIMM×1(Intel J4125/J6412)

    2×DDR3 1333/1600MHz SO-DIMM Slot, Max. 16GB

    DDR4 SODIMM ×2 (8th~12th gen.)

    Storage

    8GB; 16GB/32GB/64GB/128G Optional


    1×mSATA, 1×SATA

    1×M.2 (not available for J1900) Default to 64GB SSD

    1×mSATA, 1×SATA

    1×M.2 Default to 64GB SSD

    GraphicsSupports max. 4K resolutionIntel HD/UHD Graphics (By CPU)Intel HD/UHD Graphics (By CPU)
    I/O

    1 × HDMI; 2 × USB Max. 4× USB; 1 × USB OTG(Optional); 1 × COM(Optional);

    1 × TF Card Support 8~128GB

    1×VGA Output; 1×HDMI Output; 2×USB 3.0; 2×USB 2.0 max. 6; 2×COM port max. 6; 1×Realtek ALC662

    Line-Out /MIC IN

    1×VGA Output; 1×HDMI Output; 2×USB 3.0; 2×USB 2.0 max. 6; 2×COM max. 6; 1×Realtek ALC662

    Line-Out /MIC IN

    LAN1×10/100/1000Mbps Ethernet1× 10/100/1000Mbps Ethernet( Dual LAN optional)1×10/100/1000Mbps Ethernet( Dual LAN optional)
    OS

    Android 7.1/8/10/11/12, etc.

    Linux Ubuntu(optional)

    Windows 7/10, Linux

    Windows 11(available for J4125/J6412)

    Windows 7/10, Linux

    Windows 11(available for 7th gen. or above)

    GENERAL

    PowerInput VoltageAC100~240V input
    Operation/Power Saving40~70W
    Environment ConsiderationsOperating Temperature-20~60℃
    Storage Temperature-20~70℃
    Relative Humidity10%~80%(Non-Condensing)

    Product Image
