    Customize 15.6'' PCAP Flat Bezel panel mounted Touch LCD Panel PC All In One Fanless with RFID reader and finger printer

    Ask Lasest Price
    Brand Name : ITD/OEM
    Model Number : ITD156PPCT5KI*-NFC/RFID
    Certification : CE,FCC, RoHS Compliance
    Price : TBA
    Payment Terms : T/T
    Delivery Time : 10-15 Business days
    • Product Details
    • Company Profile

    Customize 15.6'' PCAP Flat Bezel panel mounted Touch LCD Panel PC All In One Fanless with RFID reader and finger printer

    INTRODUCTION

    ITD 15.6” multi-touch screen HMI comfort panel PC is fully-integrated‚ multi capacitive touch screen combines high-performance Intel® Core™ Dual/Quad Core Processor i3/i5/i7, and Projected Capacitive Touch (PCT or PCAP)Technology in industrial-grade LCD flat panels, combined with a NFC or RFID reader with sleek and flat front surface industrial design. This PCT technology is a capacitance system that delivers sensitive and accurate 10 multi-touch interactive experiences. The ITD 15.6” multi-touch HMI comfort panel PC specifically suited for various smart access control systems.

    FEATURES

    ▪Easy-to-clean, true flat front surface without bezel

    ▪ Card Reader like NFC, RFID, etc integrated

    ▪ Ten independent touch points with anti-vandalism & scratch

    ▪ Responds to a light touch to activate response

    ▪ Eliminates dust and debris build-up at the edge and corners of the display

    ▪ Provides improved power efficiency and reduced consumption

    ▪ Ruggedized levels of NEMA 4, IP65 ratings for front panel

    ▪All steel and aluminum frame construction designed for public and industrial environments

    ▪ CE, FCC, RoHS Compliance

    OPTIONS

    •WIFI, Bluetooth

    •Camera, Microphone built-in

    •VESA brackets, desktop stand


    SPECIFICATION

    SystemCPUIntel® Core i3/i5/i7 Processor
    BIOSAward BIOS 4/8Mbit SPI Flash ROM
    Memory1 x SO-DIMM, DDR3 1333MHz Memory, 4GB, Max.16GB
    ChipsetIntel Valley View SSA‐Cunit
    Storage64G SSD
    Graphic ChipsetCPU integrated graphics HD and support 1080p
    LAN1 x 10/100/1000Mbps Ethernet
    PanelCell Type/Glass SurfaceColor TFT LCD
    Aspect Ratio/Size15.6''/16:9
    Active Area/Pixel Pitch344.16(W) × 193.59(H)mm/0.17925 × 0.17925mm
    Native Resolution/Colors1920 x 1080
    Response Brightness/Contrast300cd/㎡ /500:1
    Viewing Angle(Typical)160/160
    Light SourceLED backlight with 50000hours’lifetime
    Input / OutputSerial Ports1 x COM
    USB Ports4 X USB
    HDMI Port1x HDMI Output
    VGA Port1 x VGA Output
    Audio Card

    with Realtek ALC662 Line-In/Line-Out/Speaker out with 3W AMP Circuit/MIC IN

    PowerInputDC 12V
    Operation/Power Saving58W
    Operating Temperature-10℃~60℃
    Storage Temperature-20℃~70℃
    Relative Humidity10%~90% (Non Condensing)
